HOME

APEX 5040 GEN3

Roof Capacity of 102,000LBS
Trim Height 30FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting

Comes in 3 versions:
Basic w 8′ Flybays
Extended w 14′ Flybays, Blow thru rear & Banner Kit
“BEAST” mode w 25′ Flybays, wings, tech coverings & black back/side walls

based out of Miami, FL

APEX 5040 GEN3 SPECS

Sam575

Roof Capacity of 92,000LBS
Trim Height 30FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Wind walls (For all upstage sides)

based out of North Central FL

SAM 575 SPECS

APEX 4240

Roof Capacity of 58,000LBS
Trim Height 27.5FT from stage height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Blow Thru or Solid Wind walls.
8′ or 14′ Flybays

based out of Miami, FL

APEX 4240 SPECS

SL320

Roof Capacity of 26,000LBS
Trim Height 25.5FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Windwalls

based out of North Central FL

SL320 SPECS

APEX 3224

Roof Capacity of 8,000LBS
Trim Height 18FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Blow Thru or Solid Wind walls.

multiple units based out of Miami & North Central FL

APEX 3224 SPECS

SL260

Roof Capacity of 12,000LBS
Trim Height 17FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Windwalls

based out of North Central FL

SL260 SPECS

APEX 2420 MIAMI FLORIDA

APEX 2420

Roof Capacity of 14,500LBS
Covered Roof 22’9”” x 26’ Deck to Roof Top 12‘10“
Deck to Front-stage 11’11”’ I-beam Deck to Center 11’8“ I-beam Deck to Back-stage I-beam 11‘5”
Beam Loads:
Fly Bays 4@2,000each
Front-stage I-beam 1,000# evenly dist.
Center I-beams 2@750# evenly dist.
Back-stage I-beam 1,000# evenly dist.
PTR Cantilever 1,000 evenly dist.
Fly Bay Bar Length 2‘3“

multiple units based out of Miami & Central FL

APEX 2420 SPECS

SL100

Roof Capacity of 6,500LBS
Trim Height 15FT from deck height
(2) Stair Units
Stage Guardrail
Stage Skirting
Stage Header Banner Kit
Set-up x2 0H30
Wind resistance 115 mph without windwalls | 77 mph with windwalls
Rigging 11,400 lb
Windwalls Full height rainproof windwalls on 3 sides
Towing Dry weight: 9,460 lb – Towable with a standard pickup truck
Popular Feature Bandshell configuration – 24’ x 12’ & multi-level mixing position

based out of North Central FL
SL100-SPECS

APEX 2016

APEX 2016 Mobile stage. Featuring a 20′ x 16′ stage deck (with 12′ 10″ of stage height). This stage is small, but produces no compromises for a stage this small. It has excellent fit and finish, solid build, can fly 800 lbs on each of the flybays with a total roof capacity of 3400 pounds.

multiple units based out of Miami, FL

APEX 2016 SPECS

APEX 2424

The APEX 2424 is identical to the APEX 3224 with as much roof load capacity but with a 24’ footprint that caters to a smaller audience. It can be purchased as a regular stage or with the drop-down floor, deck extensions, and “eyebrow” that makes it an APEX 2424 Mix.

multiple units based out of Miami, FL

APEX 2424 SPECS
